wondec ınsulatıng glass technology
Double Glass is indispensable for buildings for insulation. For quality and trouble-free production, Wondec Double Glazing Insulating Glass production lines are ready to meet all the needs of your businesses.
Wondec is one of the leading companies in the industry and meets all the requirements of the industry in the most effective and appropriate way regarding double glass production line machinery and equipment, and introduces you to the highest technology of the industry in double glazing.
Automatıc Insulatıng Glass Double Press Gas Fıllıng Productıon Lıne
VIDEO GALLERY
- PLC control, conveying speed controlled by frequency converter, touch screen operation.
- Integrated screen display, dynamic display of equipment operation and failure.
- Automatic Low-E glass detection, unique All-Low-E brushes design.
- Beam type automatic lifting and conveying glass, servo motor precise control, overcome the friction trace of back wheel when conveying jumbo glass.
- Jumbo glass aluminum frame positioning system, can solve technical problems and improve glass quality. (Optional)
- Double IGU/triple IGU/quadruple IGU can be produced by outer assembly of IG line.
- Inside assembly IG line can produce stepped IGU. (optional)
- The IG line is fully digitalized, and equipped with unique flexible thickness measurement technology for both glass and spacer.
- Both IGU assembly and panel press are controlled by servo system, accurate and reliable.
- Online argon inflation in panel press, high inflation speed and high concentration, and the inflation concentration is displayed on the screen in real time.
- Glass washing section can automatically adapt for jumbo size glass and super-thick glass processing.
- With double station mode, two pieces of glass with the same size can be processed at the same time.
- Openable panel press, which is convenient for maintenance.
Automatıc Insulatıng Glass Crossbeam Gas Fıllıng Productıon Lıne
- Automatic PLC control, full frequency converter control speed regulation, touch screen operation.
- Integrated screen display, dynamic display of equipment operation and trouble shooting.
- Automatic identification of Low- e glass, unique all-Low- e brush design.
- Double-glass/triple-glass/quadruple-glass can be produced by the insulating glass production line.
- Inside assembling of insulating glass production line can produce step unit of insulating glass. (optional)
- The insulating glass production line is fully digitalized and has the unique function of measuring the thickness of glass/aluminum frame.
- The panel press is filled with inert gas, which has high inflation speed and high concentration, and the inflation concentration is displayed on the screen in real time.
- Servo motors are used to control the pressing of insulating glass and the aluminum frame section, so the operation is accurate and reliable.
- Panel press can be opened, which is convenient for equipment maintenance.
- Automatic PLC control, full frequency converter control speed regulation, touch screen operation.
- Integrated screen display, dynamic display of equipment operation and failure.
- Automatic identification of Low- e glass, unique all-Low-e brush design.
- Beam-type automatic lifting conveying glass, servo motor precise control, overcome the friction trace of back wheel when conveying large plate glass.
- Double-glass/triple-glass/quardruple-glass can be produced by outer assembly of IGU production line.
- Inside assembling of insulating glass production line can produce step unit of insulating glass. (optional)
- The insulating glass production line is fully digitalized and has the unique function of measuring the thickness of glass/aluminum strips.
- Servo motors are used to control the pressing of insulating glass and the aluminum frame section, so the operation is accurate and reliable.
- The Panel press is filled with inert gas, which has high inflation speed and high concentration, and the inflation concentration is displayed on the screen in real time.
- Super-large and super-thick glass, cleaning brush and air knife have opening and closing functions, and the load-bearing transmission runs automatically.
- Panel press can be opened, which is convenient for equipment maintenance.
Automatıc Insulatıng Glass Double Statıon Gas Fıllıng Productıon Lıne
- Automatic PLC control, full frequency converter control speed regulation, touch screen operation.
- Integrated screen display, dynamic display of equipment operation and failure.
- Automatic identification of Low- e glass, unique all-Low-e brush design.
- Double-glass/triple-glass/quardruple-glass can be produced by outer assembly of IGU production line.
- Inside assembling of insulating glass production line can produce step unit of insulating glass. (optional)
- The insulating glass production line is fully digitalized and has the unique function of measuring the thickness of glass/aluminum strips.
- Servo motors are used to control the pressing of insulating glass and the aluminum frame section, so the operation is accurate and reliable.
- The panel press is filled with inert gas, which has high inflation speed and high concentration, and the inflation concentration is displayed on the screen in real time.
- When cleaning glass, the air knife can automatically adjust the distance according to the glass thickness. (optional)
- With double-station mode, two pieces of glass with the same size can be processed at the same time.
- Panel press can be opened, which is convenient for equipment maintenance.
Automatıc Insulatıng Glass Gas Fıllıng Productıon Lıne
Automatıc Insulatıng Glass Productıon Lıne
- Automatic PLC control, full frequency converter control speed regulation, touch screen operation.
- Integrated screen display, dynamic display of equipment operation and trouble shooting.
- Automatic identification of Low- e glass, unique all-Low- e brush design.
- Double-glass/triple-glass/quadruple-glass can be produced by the insulating glass production line.
- Inside assembling of insulating glass production line can produce step unit of insulating glass. (optional)
- The insulating glass production line is fully digitalized and has the unique function of measuring the thickness of glass/aluminum frame.
- Servo motors are used to control the pressing of insulating glass and the aluminum frame section, so the operation is accurate and reliable.
- When cleaning glass, the air knife can automatically adjust the distance according to the glass thickness. (optional)
- Customized production line in super-large glass composite sheet.(optional)
- Production efficiency: about 800 pieces can be produced in 8 hours per shift.
Super Spacer Insulatıng Glass Gas Fllıng Productıon Lıne
- Automatic PLC control, full frequency converter control speed regulation, touch screen operation.
- Integrated screen display, dynamic display of equipment operation and failure.
- Automatic identification of Low- e glass, unique all-Low-e brush design.
- Double-glass/triple-glass/quardruple-glass can be produced by outer assembly of IGU production line.
- Super spacer bar assembly platform can realize the functions of bar laying and glass conveying.
- Super spacer and aluminum bar glass processing can be switched freely, and the operation is simple.
- The insulating glass production line is fully digitalized and has the unique function of measuring the thickness of glass/aluminum strips.
- Servo motors are used to control the pressing of insulating glass and the aluminum frame section, so the operation is accurate and reliable.
- The panel press is filled with inert gas, which has high inflation speed and high concentration, and the inflation concentration is displayed on the screen in real time.
- Panel press can be opened, which is convenient for equipment maintenance.
